| 號 | 型號 | 材質 | 質量 (kg) | 外形尺寸 L×D×H mm | 熱阻 Rsa ℃/W | 流阻 ΔP Pa | 臺面 直徑 φD mm | 應用 |
| 1 | SF11 | ZL102 | 2 | 170×110× 125 | ≤0.120 | ≤40 | 45 | / |
| 2 | SF12 | ZL102 | 2.6 | 200×110× 125 | ≤0.090 | ≤45 | 50 | / |
| 3 | SF13 | ZL102 | 3.5 | 220×120× 130 | ≤0.071 | ≤55 | 50 | / |
| 4 | SF14 | ZL102 | 4.9 | 250×140× 145 | ≤0.056 | ≤60 | 65 | / |
| 5 | SF15 | ZL102 | 6.0 | 280×140× 165 | ≤0.048 | ≤65 | 65 | / |
| 6 | SF16 | ZL102 | 10.0 | 280×180× 200 | ≤0.037 | ≤70 | 80 | / |
| 7 | SF17 | ZL102 | 12 | 300×200× 215 | ≤0.030 | ≤75 | 80 | / |
| 8 | SF17A | ZL102 | 12 | 300×200× 224 | ≤0.030 | ≤75 | 80 | / |
| 9 | SS11 | T2-R | 0.7 | 140×135× 145.5 | ≤0.026 | / | 40 | / |
| 10 | SS12 | T2-R | 1.1 | 190×160× 152 | ≤0.018 | / | 50 | / |
| 11 | SS13 | T2-R | 1.6 | 190×160× 152 | ≤0.015 | / | 65 | / |
| 12 | SS14 | T2-R | 2.2 | 220×195× 188 | ≤0.013 | / | 80 | / |
| 13 | SFY2A | ZL101 | 4.3 | 180×110× 207 | ≤0.070 | ≤50 | 50 | DF4 |
| 14 | SFY2B | ZL101 | 4.3 | 180×110× 207 | ≤0.070 | ≤50 | 50 | DF7 |
| 15 | SFY2C | ZL101 | 4.3 | 180×110× 207 | ≤0.070 | ≤50 | 50 | |
| 16 | RFY1 | 6.3 | 178×300× 158 | ≤0.030 | 70 | DF4 | ||
| 17 | SFY4 | ZL101 | 6.4 | 200×125× 225 | ≤0.045 | ≤85 | 60 | DF11 |
| 18 | SFY3B | ZL101 | 6.4 | 250×140× 160 | ≤0.045 | ≤95 | 68 | SS3B |
| 19 | SFY5 | ZL101 | 8.5 | 222×144× 237 | ≤0.035 | ≤139 | 65 | SS4G |
| 20 | SFY7 | 全銅 | 11.5 | 232×127× 247 | ≤0.040 | ≤78 | 64.3 | SS7 |
| 21 | SFY8 | 全銅 | 13.0 | 222×145× 237 | ≤0.040 | ≤128 | 64.3 | SS8 |
| 22 | SFY5A | ZL101 | 8.8 | 222×144× 237 | ≤0.035 | ≤139 | 80 | |
| 23 | SFY9 | 全銅 | 21.0 | 253×168×278 | ≤0.035 | 75 | SS6B | |
| 24 | SFY8 | 全銅 | 13.0 | 246×145×246 | ≤0.040 | ≤128 | 64.3 | SS4B |
| 25 | SFY7 | 全銅 | 12.0 | 232×127×247 | ≤0.040 | ≤78 | 64.3 | SS7C |
| 26 | SFY9 | 全銅 | 19.0 | 253×168×256 | ≤0.035 | 75 | SS9 |
